+Features
✧ During the surgery of the sick pets, providing the anaesthesia machine stable and timely oxygen source and timely oxygen source through the oxygen concentrator, which greatly guarantees the smooth progress of the surgery.
Specification
| VET-5KW ; VET-10 | |||
| Flow Rate | 0.5--5L/min ; 0.5--10L/min | Net weight | 15Kgs ; 27Kgs |
| Oxygen Concentration | 93% (±3%) | Power Consumption | ≤ 350W ; ≤ 880W |
| Outlet Pressure | 6-10 PSI (0.04-0.07 Mpa) | Input Frequency | 50Hz ; 60 Hz |
| Sound Level | ≤ 40dB; ≤ 50dB | Input Voltage | AC230V ± 10%；AC110V ±10% |
| Alarm |
1. Power failure alarm; 2. High and low pressure alarm; 3. Low oxygen concentration alarm: When oxygen purity is >82%, blue light illuminate; When oxygen purity is <82%, red light illuminate, indicating low purity; |
||
Applications
✧ Supply oxygen for anesthesia, postoperative recovery, ICU, first aid and etc
✧ Eliminates the need for oxygen tanks or an in-house oxygen source.
✧ Extracts nitrogen from room air and outputs oxygen at 90% minimum purity.
✧ Eliminates labor costs and the inconvenience of tank changes.
✧ Quiet operation.
✧ Support presetting oxygen-producing time, and will automatically stop working when time up.
✧ Maximum output flow rate of up to 10LPM.
✧ Able to supply oxygen to multiple systems simultaneously.
✧ Four flexible castors with two brakes, easy to move or situate in any direction, safer and more convenient.
