+Features
✧ Oxygen sensor is aimed for oxygen concentration and flow rate monitor;
✧ It adopts ultrasonic technology with high accuracy, strong anti-interference ability, rapid response, and long service life features.
Specification
| JAY-110A | |||
| Flow Resolution | 0.1L/min | Weight | 25g |
| Max Pressure | 150Kpa | Size (mm) | 120.5(L)*22(W)*22(H) |
| Power | DC5V-12V | Max Flow | 10LPM |
| Flow Detection Accuracy | ±2%L/min or readings 5% (MAX) | ||
| LED Indicator |
Red: oxygen purity＜82% Blue: oxygen purity≥82% Yellow: flow rate＜0.5L/min |
||
| Purity Detection Accuracy | ±2%L FS@ (5-55)℃ | ||
| Output | UART port support purity and flow signal output | ||
Applications
✧ Designed to measure oxygen concentration and flow rate of oxygen concentrator
