+Features
✧ The emergency switch ensure the safety of machine operation;
✧ Two or more sets of fans ensure the machine's operating temperature and more conducive to heat dissipation；
✧ Four big wheels easy to move flexibly；
✧ Two sets of filters easy to maintain the oxygen generator;
✧ Optional booster pump: 2-8 Bar；
✧ Small centralized oxygen supply: Oxygen supply to clinic and small hospital;
✧ Sufficient flow, high oxygen concentration;
✧ Core control technology, special for industry;
✧ Reasonable structure design, convenient maintenance;
✧The booster pump and oxygen storage tank can be optional to configure a small central oxygen supply system to centrally supply oxygen to a small hospital with 100 beds.
Specification
| JAY-10D ; JAY-40 ; JAY-60 | |||
| Flow Rate | 1-20L/min ; 1-40L/min ; 1-60L/min | Net weight | 95 Kgs ; 160Kgs ; 245Kgs |
| Oxygen Concentration | 93% (±3%) | Power Consumption | ≤1100W ; ≤2200W ; ≤3300W |
| Outlet Pressure | 6-10PSI (0.04-0.07MPA ) ; 20PSI (0.14Mpa) | Input Frequency | 50Hz ; 60 Hz |
| Sound Level | ≤ 60dB | Input Voltage | AC 230V± 10% ; AC110V ± 10% |
| Alarm |
1. Power failure alarm; 2. High and low pressure alarm; 3. Low oxygen purity alarm: When oxygen purity is >82%, blue light illuminate; When oxygen purity is <82%, red light illuminate, indicating low purity; |
||
Applications
✧ For hospital with 5-100 beds;
✧ For ventilator in Intensive Care Unit (ICU);
✧ For anaesthesia machine in operating room;
✧ For high pressure cylinder filling plant.
