+Features
✧ Ultra quiet, small size and light weight.
✧ Convenient daily maintenance.
✧ Easy to read LCD display and simple control.
✧ With wheels and handle, easy to move.
✧ Inhale high purity oxygen (93%+-3%) at home.
✧ With pulse flow setting for JAY-3EP model (equivalent to 9lpm)
Specification
| Model | JAY-3EP |
| Flow Rate | 0.5-3L/min (Continous Flow) |
| Modes | Pulse Dose; Continuous |
| Pulse Mode (Settings) | Setting1: 6L; Setting2: 9L |
| Outlet Pressure | 0.09Mpa |
| Oxygen Concentration | 93%(±3%) |
| Sound Level | ≤39dB |
| Power Consumption | 280W |
| Net Weight | 12Kgs |
| Dimension | 335*215*450mm |
| Alarms |
1. Power off alarm; 2. High&low pressure alarm; 3. Low oxygen concentration alarm; |
Applications
✧ Two modes of oxygen supply are available, continuous flow and pulse flow setting to meet patients' needs;
✧ It can use the continuous flow feature with CPAP and BiPAP machines for sleep apnea and other respiratory diseases;
✧ It can be applied for those who suffer from COPD, sleep apnea, breathing difficulties, or other respiratory diseases.
